Automotive & Heavy-Duty ECU Board Repair Ebook

Notice:
This is not a physical product; no shipping is required.
The account and password for the e-book will be provided after the order is placed.
ONLINE Reading only.

What You'll Learn

• ECU electronic component fundamentals

• SMD component identification
• Diode, transistor and MOSFET testing
• Power-supply and voltage-regulation circuits
• Injector high-side and low-side driver circuits
• Boost and high-voltage ECU circuits
• CAN communication and signal-processing sections
• Current-sensing and protection circuits
• CPU, RAM, EEPROM and memory identification
• Real automotive and heavy-duty ECU board layouts
• ECU disassembly examples and repair-tool overview

Whether you work with cars, commercial vehicles, diesel engines or heavy-duty ECUs, this guide provides a practical visual reference to help you better understand ECU electronics and approach circuit-board diagnosis with greater confidence.

Who It's For

For automotive technicians, ECU repair specialists, diagnostic professionals and electronics enthusiasts who work on car, commercial-vehicle, diesel and heavy-duty ECUs and want a practical visual reference for board-level diagnosis.

Table of Contents

• ECU electronic component fundamentals
• SMD component identification
• Resistors, capacitors, inductors and ferrite beads
• Diode, transistor and MOSFET testing with a multimeter
• Crystal oscillators and clock circuits
• Power-supply and voltage-regulation circuits
• Injector high-side and low-side driver circuits
• Boost and high-voltage ECU circuits
• CAN communication and signal-processing sections
• Current-sensing and protection circuits
• CPU, RAM, EEPROM and memory identification
• Bosch EDC7, EDC16 and EDC17 board overviews
• Cummins CM800, CM2220 and CM2880 board overviews
• Hino Denso C31, Delphi DCM3.2, Weichai, Xichai, Yuchai and EControls boards
• ECU disassembly examples and repair-tool overview
